The PMBH61DDR3 Micro-ATX Motherboard (17 × 21.5 cm) is an effective option for everyday computing. It is built on the Intel H61 chipset with LGA 1155 socket support for 2nd and 3rd Gen Intel Core i3, i5, i7, and i9 processors. It supports DDR3 memory with two DIMM slots, allowing for up to 16GB of RAM at 1066 / 1333 / 1600 MHz and dual-channel support, ensuring smooth and steady performance for home, office, and business PCs.

The motherboard is designed for flexibility, with one PCIe x16 slot, one PCIe x1 slot and M.2 NVMe/NGFF slot for extension, as well as three SATA ports for storage devices. The back I/O panel features HDMI and VGA outputs, 6x USB 2.0 ports, 3-in-1 audio jacks, and 10/100 Mbps LAN connectivity. Additional features include AMI BIOS, front USB and audio connectors, CPU and system fan headers, and a 20+4 pin power connector, making installation simple. It supports Windows, Linux, and Chrome OS, and includes a motherboard, I/O panel, SATA cable, driver disk, and user manual.

Specification	Details
Model	PMBH61DDR3
Form Factor	Micro ATX (17 x 21.5cm)
Chipset	H61
CPU Support	2nd and 3rd Gen
Socket	LGA  1155
Processor Support	Inter Core i3/i5/i7/i9
BIOS	AMI
Memory Type	DDR3
Memory Slots	2 x DIMM
Maximum Memory	16GB (8GB x 2)
Memory Speed	1066MHz, 1333MHz, 1600 MHz
Dual Channel Support	Yes
PCIe x16 Slots	x1
PCIe x 1  Slots	x1
SATA Ports	x3
I/O Panel	1 x HDMI  |  1 x VGA  |  6 x USB2.0  |  3 in 1 Audio  |  LAN (RJ45) 10/100Mbps
Expansion Slots	PCIe x 16  |  PCIe x 1
HDMI Ports	x1
VGA Port	x1
USB Rear Ports	USB 2.0 x 6
USB Front Header	Yes
LAN	10/100 Mbps
Audio	Line in / Line out / Mic In
Front Audio	yes
Fan Header	CPU Fan  |   System Fan
Power Connector	20+4Pin
OS Support	Windows / Linux / Chrome OS
Accessories	1 x Motherboard  / 1 x I/O Panel  / 1 x Blue Ray Disk / 1 x User Manual / 1 x SATA Cable
